QNAP TS-932PX-4G NAS | 9-Bay High-Speed 10GbE Network Storage
The QNAP TS-932PX-4G is a high-performance 9-bay network-attached storage system designed for small and medium-sized businesses. Powered by a quad-core 1.7GHz processor and 4GB DDR4 RAM, it combines HDD and SSD storage with high-speed 10GbE connectivity, SSD caching, and reliable data protection for efficient business workflows.
Engineered for High-Speed Business Storage and Data Management:
- Powerful Processing: AnnapurnaLabs Alpine AL324 quad-core 1.7GHz processor with 4GB DDR4 RAM, expandable up to 16GB.
- Flexible 9-Bay Storage: Five 3.5-inch SATA HDD bays and four 2.5-inch SATA SSD bays with SSD caching and Qtier auto-tiering.
- High-Speed Network Connectivity: Dual 10GbE SFP+ and dual 2.5GbE RJ45 ports for fast file transfers and efficient network performance.
- Advanced Data Protection: Supports RAID configurations, block-based snapshots, and Hybrid Backup Sync for secure backup and disaster recovery.
Specification
| CPU | AnnapurnaLabs Alpine AL324 ARM® Cortex-A57 4-core 1.7GHz processor |
| CPU Architecture | 64-bit ARM |
| Encryption Engine | |
| System Memory | 4 GB SODIMM DDR4 |
| Maximum Memory | 16 GB (1 x 16 GB) |
| Memory Slot | 1 x SODIMM DDR4 |
| Flash Memory | 512 MB (Dual boot OS protection) |
| Drive Bay | 5x 3.5-inch+ 4 x 2.5-inch SATA 6Gb/s |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: |
| Hot-swappable | |
| SSD Cache Acceleration Support | |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
| 10 Gigabit Ethernet Port | 2 x 10GbE SFP+ |
| Wake on LAN (WOL) |
Only the 2.5GbE port
|
| Jumbo Frame | |
| USB 3.2 Gen 1 port | 3 |
| Form Factor | Tower |
| LED Indicators | System Status, LAN, USB, HDD1~5, SSD1-4 |
| Buttons | Power, Reset, USB Copy |
| Dimensions (HxWxD) | 176.5 × 224.6 × 224.1 mm
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
|
| Weight (Net) | 4.66 kg |
| Weight (Gross) | 5.2 kg |
| Operating Temperature | 0 – 40 °C (32°F – 104°F) |
| Storage Temperature | -20 – 70°C (-4°F – 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | External, 120 W, AC 100 to 240 V |
| Power Consumption: Disk Standby Mode | 23.833 W |
| Power Consumption: Operating Mode, Typical | 43.003 W
Tested with drives fully populated.
|
| Fan | 1 x 140mm, 12VDC |
| System Warning | Voice prompts or Buzzer |
| Kensington Security Slot | |
| Max. Number of Concurrent Connections (CIFS) – with Max. Memory | 700 |
