TerraMaster F2-425 2-Bay NAS Storage | 4K Media Server
The TerraMaster F2-425 is a powerful 2-bay NAS designed for home and SOHO environments. Powered by an Intel N5095 Quad-Core processor and 4GB DDR4 RAM, it delivers reliable data storage, smooth 4K transcoding, and high-speed file access for seamless multimedia management.
Engineered for Home & Office Efficiency:
- Powerful Processing: Intel Celeron N5095 CPU (up to 2.9 GHz).
- Fast Connectivity: 1x 2.5GbE RJ45 port for rapid file transfers.
- Multimedia Ready: 4K hardware decoding & AI-powered photo management
Specification
| Specification | Details |
|---|---|
| Processor Model | Intel Celeron N5095 |
| Processor Architecture | x86 64-bit |
| Processor Frequency | Quad Core 2.0 GHz (Max burst up to 2.9 GHz) |
| CPU Single-Core Score | / |
| Hardware Transcoding Engine | H.264, H.265, MPEG-4, VC-1; Max resolution: 4K (4096 × 2160); Max FPS: 60 |
| Hardware Encryption Engine | √ |
| System Memory | 4 GB DDR4 non-ECC SODIMM |
| Pre-installed Memory Module | 4 GB DDR4 non-ECC SODIMM (1 × 4GB) |
| Total Memory Slot Number | 1 (DDR4 SODIMM) |
| Maximum Supported Memory | 16 GB DDR4 non-ECC SODIMM |
| Disk Slot Number | 2 |
| Compatible Drive Types | 3.5″ SATA HDD, 2.5″ SATA HDD, 2.5″ SATA SSD |
| Maximum Internal Raw Storage Capacity | 60 TB (30 TB × 2) (Capacity may vary by RAID types) |
| RAID Migration | √ |
| Drive Hot Swap | √ |
| File System (Internal) | Btrfs, EXT4 |
| File System (External) | EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS |
| RJ-45 2.5GbE Network Port | 1 |
| USB 3.2 Host Port | 2 × 10 Gbps + 1 × 5 Gbps |
| HDMI | 1 × HDMI |
| Size (H × W × D) | 222 × 119 × 154 mm |
| Packaging Size (H × W × D) | 258 × 220 × 170 mm |
| Weight | Net: 1.5 kg, Gross: 2.3 kg |
| System Fan | 80 × 80 × 25 mm, 1 PCS |
| Fan Mode | Smart, High speed, Middle speed, Low speed |
| Noise Level | 19.0 dB(A) (Using 2 drives in standby; test distance: 1 m) |
| Power Supply | 48 W |
| Redundancy Power Supply | / |
| AC Input Voltage | 100V – 240V AC |
| Current Frequency | 50/60 Hz, Single phase |
