TerraMaster F4-425 Plus 4-Bay NAS | Intel N150 Quad-Core Processor
The TerraMaster F4-425 Plus is a powerhouse 4-bay NAS designed for high-speed data management. Powered by an Intel N150 Quad-Core CPU and 16GB DDR5 RAM, it delivers exceptional performance for SMBs and 4K media streaming.
Next-Gen Connectivity & Power:
- Dual 5GbE Networking: Blazing network speeds up to 1020 MB/s.
- Triple M.2 NVMe Slots: Three dedicated slots for flexible SSD caching.
- 16GB DDR5 Memory: Superior bandwidth for smooth multitasking .
Specification
| Specification | Details |
|---|---|
| Processor Model | Intel® N150 Quad-Core |
| Processor Architecture | x86 64-bit |
| Processor Frequency | Max burst up to 3.6 GHz |
| CPU Single-Core Score | / |
| Hardware Transcoding Engine | H.264, H.265, MPEG-4, VC-1; Max resolution: 4K (4096 × 2160); Max FPS: 60 |
| Hardware Encryption Engine | √ |
| System Memory | 16 GB DDR5 non-ECC SODIMM |
| Pre-installed Memory Module | 16 GB DDR5 non-ECC SODIMM (1 × 16 GB) |
| Total Memory Slot Number | 1 (DDR5 SODIMM) |
| Maximum Supported Memory | 32 GB DDR5 non-ECC SODIMM |
| Disk Slot Number | 4 |
| Compatible Drive Types | 3.5″ SATA HDD, 2.5″ SATA HDD, 2.5″ SATA SSD |
| Maximum Internal Raw Storage Capacity | 120 TB (30 TB × 4) (Capacity may vary by RAID types) |
| M.2 2280 NVMe Slot | 3 (PCIe 3.0 ×1) |
| Drive Hot Swap | √ |
| File System (Internal) | Btrfs, EXT4 |
| File System (External) | EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS |
| RJ-45 5GbE Network Port | 2 |
| USB 3.2 Host Port | 3 × Type-A + 1 × Type-C |
| HDMI | 1 × HDMI |
| Size (H × W × D) | 150 × 181 × 219 mm |
| Packaging Size (H × W × D) | 186 × 277 × 277 mm |
| Weight | Net: 2.9 kg, Gross: 4.1 kg |
| System Fan | 120 × 120 × 25 mm, 1 PCS |
| Fan Mode | Smart, High speed, Middle speed, Low speed |
| Noise Level | 20.9 dB(A) (Using 4 drives in standby; test distance: 1 m) |
| Power Supply | 90 W |
| Redundancy Power Supply | / |
| AC Input Voltage | 100V – 240V AC |
| Current Frequency | 50/60 Hz, Single phase |
