TerraMaster F4-SSD | 4-Bay All-Flash NAS
The TerraMaster F4-SSD is a compact, high-performance all-flash NAS designed for speed-critical home media and creative workflows. Powered by an Intel N95 processor and 5GbE connectivity, it delivers lightning-fast data access in a whisper-quiet, palm-sized enclosure.
Engineered for Silent Speed:
- Intel N95 Power: Quad-core 3.4GHz CPU with 8GB DDR5 RAM.
- All-Flash Architecture: 4x M.2 NVMe slots for rapid storage.
- High-Speed Network: 1x 5GbE port for up to 550MB/s transfer.
Specification
| Specification | |
| Processor | |
| Processor Model | Intel® N95 |
| Processor Architecture | x86 64-bit |
| Processor Frequency | Max burst up to 3.4 GHz |
| CPU Single-Core Score | / |
| Hardware Encryption Engine | √ |
| Hardware Transcoding Engine | H.264, H.265, MPEG-4, VC-1;maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60 |
| Memory | |
| System Memory | 8 GB DDR5 non-ECC SODIMM |
| Pre-installed Memory Module | 8 GB DDR5 non-ECC SODIMM (1x 8 GB) |
| Total Memory Slot Number | 1 × DDR5 SODIMM |
| Maximum Supported Memory | 32 GB DDR5 non-ECC SODIMM |
| Note | TerraMaster reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. |
| Storage | |
| Disk Slot Number | / |
| Compatible Drive types | / |
| / | |
| / | |
| Maximum Internal Raw Storage Capacity | 32 TB (8 TB x4) (Capacity may vary by RAID types) |
| Drive Hot Swap | / |
| Note | Hard drive vendors will release their latest models of hard drives, and Maximum internal raw storage capacity may be adjusted accordingly. The maximum single volume size is not directly related to the maximum raw capacity. |
| File System | |
| Internal Drive | Btrfs, EXT4 |
| External Drive | EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS |
| External Ports | |
| RJ-45 1GbE Network Port | / |
| RJ-45 2.5GbE Network Port | / |
| RJ-45 5GbE Network Port | 1 |
| SFP+ 10GbE Network Port | / |
| USB3.2 Host Port | 3 x 10 Gbps（Type A x2 + Type C x1) |
| USB2.0 Host Port | / |
| COM | / |
| HDMI | 1 x HDMI 2.b |
| VGA | / |
| PCIe Slots | / |
| M.2 2280 NVMe Slot | 2(PCIe 3.0 x2）+2(PCIe 3.0 x1) |
| Appearance | |
| Size (H*W*D) | 138 x 60 x 140 mm |
| Packaging Size (H*W*D) | 185 x 172 x 152 mm |
| Weight | Net Weight: 0.6Kg , Gross Weight: 1.2 Kg |
| Others | |
| System Fan | 50 x 50 x 10mm 2PCS |
| Fan Mode | Smart, High speed, Middle speed, Low speed |
| Noise Level | 19.0 dB(A) (Using M.2 SSDs in standby mode; Test environment noise: 17.3dB(A); Test distance: 1m) |
| Power Supply | 48 W |
| Redundancy Power Supply | / |
| AC Input Voltage | 100V – 240V AC |
| Current Frequency | 50/60 Hz, Single frequency |
| Power Consumption | 32.0 W(Fully loaded Seagate 2TB M.2 SSDs in read/write state) |
| 8.0 W (Fully loaded Seagate 2TB M.2 SSDs in hibernation) | |
| Limited warranty | 2 years |
| Certificate | FCC, CE, CCC, KC |
| Environment | RoHS, WEEE |
| Temperature | |
| Working Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -20°C ~ 60°C (-5°F ~ 140°F) |
| Relative Humidity | 5% ~ 95% RH |
| Package Contents | |
| Host unit (x1) | |
| Power cord (x1) | |
| Power Adapter(x1) | |
| RJ-45 network cable (x1) | |
| Quick Installation Guide (x1) | |
| Limited Warranty Note(x1) | |
| Screws (a few) | |
| TOS Features | |
| OS Supported | |
| Supported Client OS | Windows OS, Mac OS, Linux OS |
| Supported Web Browsers | Google Chrome 97.0 or later, Mozilla Firefox 9.3, Apple Safari 12.1 ; Microsoft Edge 99.0.000 or later version. |
| Supported mobile OS | iOS14.0, Android 10.0 or later version |
| Storage Management | |
| Supported RAID Types | TRAID, TRAID＋, Single, JBOD, RAID 0, RAID 1, RAID5, RAID 6, RAID 10 |
| Maximum Internal Volume Number | 128 |
| Maximum iSCSI Target | 64 |
| Maximum iSCSI LUN | 64 |
| Volume Expansion with Larger HDDs | TRAID, TRAID＋, RAID 5, RAID 6, RAID 10 |
| Volume Expansion by Adding a HDD | / |
| RAID Migration | √ |
| SSD Cache | √ |
| Hot Spare | √ |
| SSD TRIM | √ |
| Hard Drive S.M.A.R.T. | √ |
| Seagate IHM | √ |
| NVRAM write cache(BBU-protected) | / |
| Shared Folder Snapshot | √ |
| LUN Snapshot | √ |
| File Services | |
| File Protocol | SMB/AFP/NFS/FTP/SFTP/WebDAV |
| Maximum Concurrent SMB/AFP/FTP/SFTP Connections | 100 |
| Windows Access Control List (ACL) Integration | √ |
| NFS Kerberos Authentication | √ |
| Account & Shared Folder | |
| Maximum local user’s account number | 128 |
| Maximum local group number | 128 |
| Maximum shared folders number | 128 |
| Maximum shared folders syncing tasks | 8 |
| Backup | |
| Rsync Backup | √ |
| Duple Backup | √ |
| Centralized Backup | √ |
| Snapshot | √ |
| USB Backup | √ |
| Cloud Sync | √ |
| Time Machine Backup | √ |
| File System Snapshot | √ |
| TFM Backup | √ |
| Networking | |
| TCP/IP | IPv4/IPv6 |
| Protocols | CIFS/SMB, NFS, FTP, SFTP, HTTPS, SSH, iSCSI, SNMP |
| Link Aggregation | √ |
| DLNA Compliance | √ |
| VPN Client | √ |
| VPN Server | √ |
| Proxy Client | √ |
| Proxy Server | / |
| UPnP/Bonjour Discovery | √ |
| TNAS.online Remote Access | √ |
| DDNS | √ |
| Access Right Management | |
| Batch users creation | / |
| Import/Export users | √ |
| User Quota Management | √ |
| Local user access control for CIFS/SAMBA and FTP | √ |
| Domain Authentication | |
| AD Domain | √ |
| LDAP Client | √ |
| LDAP Server | / |
| Security | |
| Firewall Protection | √ |
| Account Auto-block Protection | √ |
| AES Shared Folder Encryption | √ |
| Importable SSL certificate | √ |
| Instant Alert via email, Desktop Notification, Beep | √ |
| RSA 2048 Encryption（TOS 6.0） | √ |
| PAM (Pluggable Authentication Modules) | √ |
| OTP Authentication（TOS 6.0） | √ |
| HyperLock File System（TOS 6.0） | √ |
| Power Management | |
| Power Resume | √ |
| Scheduled Power On/Off | √ |
| Wake up On LAN（WOL） | √ |
| UPS Supported | √ |
| Administration | |
| Multi-window, Multi-task System Management | √ |
| Custom Desktop | √ |
| Control Panel | √ |
| Resource Monitor | √ |
| Syslog | √ |
| OS UI Language | English, German, French, Spanish, Italian, Magyar, Chinese, Japanese, Korean, Turkish, Portuguese, Russian |
| Applications | |
| Application Center | √ |
| iSCSI Target | √ |
| Terra Photos | √ |
| TerraSync | √ |
| Duple Backup | √ |
| CloudSync | √ |
| Centralized Backup | √ |
| USB Backup | √ |
| VPN Server | √ |
| Transmission | √ |
| qBittorrent | √ |
| Aria 2 | √ |
| Terra Search | √ |
| Deduplication | √ |
| Web Server | √ |
| Clam Antivirus | √ |
| EMBY | √ |
| Multi Media Server | √ |
| Plex Media Server | √ |
| Docker Manager | √ |
| Snapshot | √ |
